Trace Moisture Sensor in Oil

The micro moisture sensor in oil is a precision analysis device used to accurately detect the moisture content in various types of oils such as lubricating oil, hydraulic oil, and fuel. Its core value lies in real-time monitoring of the moisture content of the oil, avoiding oil degradation, equipment corrosion, or lubrication failure caused by moisture. It is widely used in the fields of petrochemicals, electricity, mechanical manufacturing, transportation, etc.

Availability:

Quantity:



Inquire Add to Basket

Model:
GD-HHW350
Brand:
GOLD

Product Description

Trace Moisture Sensor in Oil

The patented measurement technology of the trace moisture sensor in oil can achieve accurate monitoring of the dissolved moisture content in various types of oil. The high reliability industrial design of the micro water content sensor in oil enables it to continuously, accurately, and quickly measure changes in water content and temperature in various types of oil under harsh environmental conditions. It can be widely used for online monitoring of water content in lubricating oil, hydraulic oil, gear oil, engine oil, fuel, and other applications.

Technical parameters of trace moisture sensors in oil:

Water activity
Measurement range	0... 1 aw
Measurement accuracy	0... 0.6 ± 0.02 aw
Measurement accuracy	0.6 … 1 ± 0.02 aw
Resolution	0.001 aw
Response time (typical)	<1 minute
Moisture content in oil (dissolved moisture)
Measurement range	0... 100ppm 500 ppm 1000ppm 2000ppm or customized
Measurement accuracy	± 10%
Temperature
Measurement range	-40... 100 ° C
Accuracy (at+25 ° C)	± 0.3 ° C
Working temperature (environment)	-40...+80 ° C
Allowable oil temperature	-40...+100 ° C
Output
Digital signal	RS485 MODBUS RTU, (RS232 optional)
Analog signal	4... 20 mA load resistance 500 Ω

Product Details Display:
