GD-510F1
GOLD
Low temperature fluidity testing project:
Pour Point: Determine the lowest temperature at which oil can flow at low temperatures (standards: GB/T 3535, ASTM D5950), and evaluate the transport and start-up performance of lubricating and fuel oils in low-temperature environments.
Solidification Point: The highest temperature at which an oil loses its fluidity at low temperatures (standards: GB/T 510, ASTM D938), suitable for analyzing the low-temperature solidification characteristics of diesel, paraffin, and other oil products.
Cold Filter Plugging Point (CFPP): simulates the clogging temperature of diesel passing through a filtering device at low temperatures (standards: SH/T 0248, EN 116), reflecting the pumping and filtering performance of the oil at low temperatures.
Cloud Point: The temperature at which wax crystals begin to precipitate and become cloudy in oil products (standard: GB/T 6986ASTM D2500）， Suitable for low-temperature wax precipitation risk assessment of light oil products such as jet fuel and diesel.
Features:
1) This instrument adopts intelligent temperature control system, display the temperature of the cold bath trough in real time. It is convenient to adjust parameter of the temperature setting and control. The temperature controlling is in high accuracy.
2) This instrument is multifunctional. It is suitable for the test of pouring point, cloud point, solidification point and cold filter plugging point.
3) Adopt metal bath, fast refrigeration, uniform temperature, eliminate the unsafe liquid bath.
4) With automatic protection function, if there’s any cold trough meet high temperature abnormality, the instrument will automatically cut off the working power of the heating tube, to avoid damage to the instrument.
5) Floor type structure, novel design, less occupation, four wheels at the bottom, easy to move.
Main technical specification and parameters:
Power supply | AC（220±10%）V 50Hz |
Cold bath temperature control | i. Cold trough I: can be set -17℃～0℃,accuracy±0.5℃, two bath isotherm ii. Cold trough II: can be set 30℃ or -34℃, and keep constant iii. Cold trough III: can be set -51℃～-34℃,accuracy±0.5℃, two bath isotherm iv. Cold trough IV: can be set 30℃ or -70℃, and keep constant |
Refrigerating method | Compressor refrigeration |
Suitable temperature | 15℃～28℃ |
Relative humidity | ≤85% |
Power consumption | less than 1700W |
Size | 810×500×840（L×W×H） |
Total weigh | 100kg |
Product details:
Low temperature fluidity testing project:
Pour Point: Determine the lowest temperature at which oil can flow at low temperatures (standards: GB/T 3535, ASTM D5950), and evaluate the transport and start-up performance of lubricating and fuel oils in low-temperature environments.
Solidification Point: The highest temperature at which an oil loses its fluidity at low temperatures (standards: GB/T 510, ASTM D938), suitable for analyzing the low-temperature solidification characteristics of diesel, paraffin, and other oil products.
Cold Filter Plugging Point (CFPP): simulates the clogging temperature of diesel passing through a filtering device at low temperatures (standards: SH/T 0248, EN 116), reflecting the pumping and filtering performance of the oil at low temperatures.
Cloud Point: The temperature at which wax crystals begin to precipitate and become cloudy in oil products (standard: GB/T 6986ASTM D2500）， Suitable for low-temperature wax precipitation risk assessment of light oil products such as jet fuel and diesel.
Features:
1) This instrument adopts intelligent temperature control system, display the temperature of the cold bath trough in real time. It is convenient to adjust parameter of the temperature setting and control. The temperature controlling is in high accuracy.
2) This instrument is multifunctional. It is suitable for the test of pouring point, cloud point, solidification point and cold filter plugging point.
3) Adopt metal bath, fast refrigeration, uniform temperature, eliminate the unsafe liquid bath.
4) With automatic protection function, if there’s any cold trough meet high temperature abnormality, the instrument will automatically cut off the working power of the heating tube, to avoid damage to the instrument.
5) Floor type structure, novel design, less occupation, four wheels at the bottom, easy to move.
Main technical specification and parameters:
Power supply | AC（220±10%）V 50Hz |
Cold bath temperature control | i. Cold trough I: can be set -17℃～0℃,accuracy±0.5℃, two bath isotherm ii. Cold trough II: can be set 30℃ or -34℃, and keep constant iii. Cold trough III: can be set -51℃～-34℃,accuracy±0.5℃, two bath isotherm iv. Cold trough IV: can be set 30℃ or -70℃, and keep constant |
Refrigerating method | Compressor refrigeration |
Suitable temperature | 15℃～28℃ |
Relative humidity | ≤85% |
Power consumption | less than 1700W |
Size | 810×500×840（L×W×H） |
Total weigh | 100kg |
