Automated Dual-Sample Pour Point & Cloud Point Tester ASTM D97 ASTM D2500
Introduction:
The GD-103 Automatic Pour Point and Cloud Point Tester is specifically made in compliance with international testing standards ASTM D97 and ASTM D2500 for determining the pour point and cloud point of petroleum products. This advanced instrument combines superior measurement accuracy with full automation capabilities, delivering reliable analytical performance through its precision-engineered design.
Technical Features:
1. 10.4-inch colored touch LCD. Built-in computer control technology. Easy to use.
2. PPT imaging technology is adopted to detect and judge the pour point automatically.
3. Fully-automation during the test. No need of human operation. Meanwhile it can save and print the test result automatically.
4. Self-diagnosis function is set to check the working condition of the instrument.
5. Imported glass temperature sensor is equipped. The test result is reliable.
6. Imported compressor. Metal-block bath. No need to use alcohol as the cooling medium. Fast cooling speed and good cooling performance.
7. Two separate test units with two independent temperature control units. It can determine two samples at a time. High working efficiency.
8. LIMS network is usable.
Technical Specifications:
No | Parameter | Specification |
1 | Power Supply | AC 220V ±10%, 50Hz ±5% |
2 | Maximum Power Consumption | 1800W |
3 | Minimum Measurable Pour Point | -51℃ |
4 | Temperature Range | -69℃ to +48℃ |
5 | Temperature Precision | ±0.5℃ |
6 | Cooling Speed | ≤15 minutes (from +48℃ to -69℃) |
7 | Test Units | 2 independent chambers |
8 | Operating Conditions | Ambient temperature: 15-35℃ |
