GD-264B
GOLD
Total Acid Total Base Number Tester by Potentiometric Titration
TAN/TBN
TBN stands for Total Base Number, while TAN is short for Total Acid Number.Both tests monitor the effective life of in-service lubricants.TAN testing helps monitor the degradation of lubricating oils over time.As oil ages, it can oxidise, leading to the formation of acidic by-products.These acidic compounds can increase the TAN value, signalling that the oil is breaking down and may need to be replaced.Total Base Number (TBN or BN) has been a key performance indicator in the field, used to determine the remaining life of engine oil by indicating the amount of performance-related additive left in the engine oil.In short, it helps determine when engine oil needs to be changed.
Introduction
The GD-264B TAN/TBN Tester is a sophisticated piece of equipment which, when used in conjunction with the relevant application software, can be used to accurately determine the acid value of petroleum products. The tester is composed of three main components: a hardware circuit, a titration device and a PC machine. The GD-264B has a simple structure, an attractive appearance and high degrees of automation and accuracy. It is an ideal intelligent instrument for use in petrochemical laboratories, analysis rooms and scientific research departments.
Implementation Standards for the GD-264B Acid Number Tester: GB/T264 Determination of acid number,GB7599-87 Determination of acid number in transformer and turbine oils in service(BTB),GB/T7304-2000,GB/T 18609-2001,ASTM D664,ASTM D2896.
Technical Features:
(1) Windows operating system, with man-machine dialogue mode for simple and intuitive operation.
(2) Key components of the titration device are all imported, ensuring stable and reliable performance, and with minimal transmission noise.
(3) Automatic cleaning, automatic fluid filling, fixed value of fluid adding, mechanical and electrical organic combination.
(4) Multi-parameter setting and correction facilitate the analysis of different kinds of samples, making it simple, fast and accurate.
(5) The end point is automatically judged, without an indicator, making it suitable for the acid value analysis of various light and dark oil in petrochemical products, titration results and data storage. It can provide complete titration data for analysis and research.
(6)The double-high resistance input, three-electrode system and stable and reliable electrode potential of the instrument ensure optimal performance.
Technical Specifications:
No | Parameter | |
1 | Power supply | AC(220±10%)V 50Hz |
2 | Total power consumption | ≤200W |
3 | Potential measurement range | (0 to ±1999.5)mV |
4 | Input impedance | Ri≥1×1012Ω |
5 | Burette volume | 10mL |
6 | Burette precision | ±0.1%F•S |
7 | Burette dripping time | (60±20)S(F·S) |
8 | Acid number measurement range | ≥0.05 mgKOH/g |
9 | Minimum titration volume | 0.001mL |
10 | Environment | temperature: 5℃~35℃ , Relative humidity: ≤ 80% |
11 | Outline dimension | About350mm×280mm×180mm(L×W×H,Without PC) |
12 | Net weight | 14Kg |
