GD-H1358
GOLD
ASTM D6278 Diesel Fuel Nozzle Shear Stability Tester for Polymer Containing Fluids Oils
Product Description：
1.The apparatus for measuring the shear stability of polymer-containing oils, diesel nozzle method, the measurement sample before and after the movement of the shear viscosity, its value drop divided by the kinematic viscosity values of viscosity before shear test results as a percentage. The device is currently the only test instrument meets ASTM D6278 Method.
2.The apparatus consists of motor, coupler, gears, oxygen bomb tray, oxygen bomb, heater, temperature controller, touched LCD screen and pressure transmitter.
Significance and Use：
1.This test method covers the evaluation of the shear stability of polymer-containing fluids. The test method measures the percent viscosity loss at 100°C of polymer-containing fluids when evaluated by a diesel injector apparatus procedure that uses European diesel injector test equipment. The viscosity loss reflects polymer degradation due to shear at the nozzle.
2. This test method evaluates the percent viscosity loss for polymer-containing fluids resulting from polymer degradation in the high shear nozzle device. Thermal or oxidative effects are minimized.
Main Technical Features：
1.Original German well-known brands jet pump with nozzle and atomizing chamber;
2. Bowch-type axial nozzle injector, the nozzle bracket has a filter cartridge;
3. The spherical cooler is equipped with a cooling jacket, which can effectively cool the oil sample and ensure that the temperature of the oil sample is between 30 and 35 °C;
4. The liquid flow meter controls the flow rate, digital display, 170cm3±5cm3/min;
5. The automatic stroke counter can automatically cut off the power supply;
6. Three-phase motor, power 1100W, speed 925±25r/min;
7. There is a distribution plate in the glass test tube, and there is a three-way piston at the cooling outlet;
8. Microcomputer temperature controller, digital display, accuracy ±1ºC, PT100 sensor;
9. Fully enclosed compressor refrigeration, large cooling capacity and low noise;
10. Digital timer records the test time with wind sound;
11. Independent desktop controller, highly integrated function buttons, easy to operate;
12. There is an electronic controller to control the pressure on the pressure pipeline, and the digital display pressure is 17.5Mpa±0.35Mpa.
13. Instrument size: host: 800*250*1100mm; circulating water bath: 240*510*670mm;
14. Net weight: 56KG
Product Parameters：
| Applicable standard | ASTM D6278, SH/T0103 |
| Timing method | Digital timer |
| Counting method | Automatic stroke counter |
| Refrigeration method | Compressor refrigeration |
| Temperature control range | 35±0.2ºC |
| Circulation mode | Magnetic pump circulation |
| Flow rate control | Liquid flow meter |
| Pressure control | Pressure transmitter, digital display |
| Machine power | 2.5KW |
| Working power supply | AC220,240V/50,60Hz |
